CS & S Bars Laser Diodes
|
| Part Number |
Output Power
(W) |
Wavelength
(nm)
25癈 |
Typical Spectral Bandwidth
FWHM |
Picture |
Description and Applications |
| JOLD-8-BAS-1E |
8 CW |
808, 976 |
3 nm |
 |
CW, Single emitter, 200 microns @ 808nm, 90 microns @ 976nm Passively Cooled, No Optics Diode Laser for pumping, printing, medical applications. |
| JOLD-8-BA-1E |
8 and 10 CW |
808, 976 |
3 nm |
 |
CW, Single emitter, 200 microns @ 808nm, 90 microns @ 976nm Passively Cooled, No Optics Diode Laser for pumping, printing, medical applications. |
| JOLD-X-BA-4E |
20 and 30 CW |
808, 915, 938, 976 |
3 nm |
 |
CS Mount, CW, PassivelyCooled, No Optics Diode Laser for pumping, printing, medical applications. |
| JOLD-X-CPNN-1L-CS |
40, 60, 80 and 100 CW |
808, 915, 938, 976 |
3 nm |
|
CS Mount, CW, PassivelyCooled, No Optics Diode Laser for pumping, printing, medical applications. |
| JOLD-200-QPNN-1L-CS |
200 QCW |
808, 915, 938, 976 |
3 nm |
|
CS Mount, QCW, PassivelyCooled, Diode Laser for pumping, printing, medical applications. |
| JOLD-X-CPNN-1L-S |
40, 60, 80 and 100 CW |
808, 915, 938, 976 |
3 nm |
 |
S Mount, CW, PassivelyCooled, No Optics Diode Laser for pumping, printing, medical applications. |
| JOLD-200-QPNN-1L-S |
200 QCW |
808, 915, 938, 976 |
3 nm |
|
S Mount, QCW, PassivelyCooled, Diode Laser for pumping, printing, medical applications. |
| JOLD-X-CPBN-1L |
50 and 55 |
808, 915, 938, 976 |
3 nm |
|
Collimated S Mount,
CW, PassivelyCooled, Both Axis Collimated Diode Laser for pumping, printing, medical applications. |
| JOLD-180-QPFN-1L |
180 QCW |
808, 915, 938, 976 |
3 nm |
|
Collimated S Mount,
CW, PassivelyCooled, Both Axis Collimated Diode Laser for pumping, printing, medical applications. | |
